    waterproof IP67 4G android smart phone
1. General Scope
◇waterproof:IP67
◇ Platform
 Operating system :Android 4.4
◇ Characteristic
 Type:LTE micro SIM(one SIM card)
 Dimensions:155*80*14.8mm
 Weight with battery:238g
 Sceeen Size/ Pixel:5.0" HD 1280*720,IPS
 Capacitive Touch Panel :Yes
 Required Keys :Touch key,Volume SIDE UP+DOWN key,Power ON key
 Battery :4050 mAh
 Internal Memory:8GB ROM+1GB RAM
 External Memory Connector:Micro SD, up to 32GB
 Camera :8.0M AF Camera by hardware
 GPS :support
 Wi-Fi:IEEE 802.11b/g/n
 Bluetooth:Yes, 4.0
 FM Radio:Yes
◇ Processor
 Qualcomm MSM8926 @ 1.2GHz QUAD CORE
◇ RF Specification
 Mode /BAND"LTE FDD B20:800/B7:2600/B1:2100MHz TDD B36/2600 B40/2300
WCDMA B8:900/B1:2100MHz
GSM B8:900/B5:850/B3:1800/B2:1900MHz
"

2. Phone Specification (Hardware)
◇ Display
 Main display resolution:HD 1280*720 pixels
 Main display color space:262K
 Main display technology :IPS
 Main display dimensions :5.0inch
 Main display touch screen Touch Lens:Yes ,Capacitive
 Main display orientation :Full orientation
◇ Main Camera
 "Main camera built-in or accessory
 ":Built-in
 Pixel :8.0M by hardware
 Camera technology:CMOS
 Auto Focus :Yes
 Zoom:Digital zoom 4X
 Picture formats:JPEG
 Video:Support video capture, simultaneity audio record
 Flash light:YES
◇ Secondary Camera
 Pixel :2.0M
 Camera technology:CMOS
◇ Keypad / Button / Switch
 Power button:Yes
 Send and End phone buttons:Yes
 Home Key :Yes
 Menu and Back Key:Yes
 Side buttons:Volume up/down keys
 Back-light color:White
◇ Storage
 ROM Flash:8GB
 RAM:1GB
 Extended Storage:Micro SD
 Max support memory card size:32GB
◇ USIM
 USIM support:Yes,WCDMA SIM slot
 SIM card slot:SIMOne
◇ USB
 USB revision USB:USB 2.0 high speed
 USB charging USB:Yes
 System I/O connector:Micro USB (5pins)
◇ Bluetooth
 Bluetooth revision:Ver 4.0
 Bluetooth power class:Class 2
 Support profile:SDP/GAP/A2DP/AVRCP/HSP/HFP/OPP/PBAP
◇ GPS
 GPS;Yes, with GPSOne Gen 7
◇ FM
 FM Radio: Yes
◇ WLAN
 WLAN revision IEEE 802.11b/g/n Support WAPI; Wireless Router
◇ Sensor
 G-Sensor:Yes
 Proximity sensor:Yes
 E-Compass :Yes

◇ Physical Interface
 Audio jack:Yes,3.5mm
 Mic :2
 Speaker:1 speaker
 Lanyard hole :Yes

◇ Battery
 Battery technology:Polymer Lithium Ion
 Battery capacity:4050mAh
 Standby time (single SIM):TBD
 Voice talk time:400minites
 Charging time :< 5 hours

3. Phone Specification (Software)
◇Language options available
 Default language:English
◇Audio
 Playback:support AMR,MIDI,MP3,AAC,MPEG4,H.263,H.264,3GP
 Recorder:supprt MPEG4, H263
 Stereo BlueTooth earphone:Support
 Handfree:Support
◇GMS
 Google Market:Yes
◇Personal assistant
 Calendar:Yes
 Alarm:Yes
 Program Management:Yes
 File Management:Yes
◇Message
 SMS:Yes
 MMS:Yes

4. In-Box Content
◇ Product
 Handset :Yes, 1
 PC Cable :Yes, 1
 AC Charger :Yes, 1
 Battery:YES, 1
 User Manual:Yes, 1
 screwdriver:yes 1
