ITEM

MODEL

C1KR/C1KRS

C2KR/C2KRS

C3KR/C3KRS

C6KR/C6KRS

C10KR/C10KRS

Capacity

VA/W

1kVA / 0.7kW

2kVA / 1.4kW

3kVA / 2.1kW

6kVA / 4.2kW

10kVA / 7kW

Input

Nominal Voltage

220 or 110VAC

220VAC

Voltage Range

115 ~ 300VAC

176 ~ 276VAC

Frequency Range

50 or 60 �� 10HZ

46 ~ 54Hz

Power Factor

0.97

0.98

Output

Voltage

220 or 110VAC �� 2%

220VAC �� 1%

50 or 60 �� 0.2Hz ( Battery mode)

50Hz �� 0.05Hz ( Battery mode)

Waveform

Pure sine wave

Overload Capability

108%~150% for 30 sec., 150% for 300 ms

105%~130% for 10 min., 130% for 1 min

Current Crest Ratio

3:01

Bypass

Automatic Transfer

on overload and UPS failure

Before UPS Power-on

Default ��NO��, user adjustable to ��YES��

Yes

Transfer Time

0 ms; less than 4 ms from inverter to bypass and vice versa

Zero

LED indicators

Status

Load level / Battery level, Battery , Utility Power, Inverter, Bypass,

Audible Alarm

Bypass, On battery mode, Battery low, Overload, Fault

Communications

RS-232 Serial Interface

Intelligent Slot;

OPTIONS: (WEBPOWER SNMP/WEB card, AS400 card or WinPower CMC)

Network Surge Protection

RJ45 I/O port available for network or Fax/Modem

REMARK

C*KR is standard type. C*KRS are longer time type
