General Specifications

Standards

ITU G.992.1 (G.dmt) Annex A, ITU G.992.2(G.lite),

ITU G.994.1(G.hs), ANSI T1.413 Issue # 2

Data Transmission Rate

G.dmt full rate and T1.413: Downstream up to 8 Mbps,

Upstream up to 896 Kbps

G.lite: Downstream up to 1.5 Mbps, Upstream up to 512 Kbps

External Interface

WAN: One RJ-11 port for ADSL line connection

LAN: One RJ-45 port for 10/100 Base-T Ethernet

Connection

Features

Supporting 1483B bridging and routing function

Supporting DHCP server, NAT/NAPT , PAP/CHAP, IP

Filter, Firewall, protocol block

Built-in PPPOE/PPPOA dialing

Physical and Environmental Specifications

Power Supply

AC: 90~240V, power adapter: 9 V AC 1A

Power Consumption

Max. 9W

Humidity

5% - 95% (non-condensing)

Dimensions

143mm x 104mm x 32mm
